Convert PDF to PCL in React with JavaScript

Many printers and print services only speak PCL (Printer Command Language). When the contract or manual at hand is a PDF, the old routes were to install a driver and save the file under a new format from desktop software, or to hand the file to a server that does the conversion — the first cannot be folded into a web workflow, and the second means the document leaves the user's device.

This article shows how to convert a PDF to PCL with Spire.PDF for JavaScript. Built on WebAssembly, it loads and saves PDF documents directly in the browser, so the whole conversion stays local and files are read and written through a virtual file system (VFS) with no backend service required.

For installation and project configuration, refer to Integrating Spire.PDF for JavaScript in a React Project. The following example assumes Spire.PDF is installed and the WebAssembly module has been initialized.

Convert PDF to PCL

To hand a document to a print pipeline that only accepts PCL, use PdfDocument.SaveToFile to write the whole document out as a PCL file — pass FileFormat.PCL as the second argument and the output is HP-PCL XL (PCL6).

function App() {
  const convertPdfToPcl = async () => {
    // Get the Spire.PDF WASM module
    const pdfModule = window.wasmModule?.spirepdf;

    // Check whether the module is ready
    if (!pdfModule) {
      alert('Spire.PDF is not ready yet');
      return;
    }

    // The conversion needs the Arial Unicode MS font, load it into the VFS first
    await window.spire.FetchFileToVFS('ARIAL UNICODE MS.TTF', '/Library/Fonts/', `${process.env.PUBLIC_URL}/font/`);

    // Load the PDF file to be converted into the VFS
    const inputFileName = 'Business_Data_Overview.pdf';
    await window.spire.FetchFileToVFS(inputFileName, "", `${process.env.PUBLIC_URL}/data/`);

    // Define the output file name
    const outputFileName = 'Business_Data_Overview.pcl';

    // Load the PDF document and pass FileFormat.PCL to write out a PCL file
    let doc = new pdfModule.PdfDocument();
    doc.LoadFromFile(inputFileName);
    doc.SaveToFile(outputFileName, pdfModule.FileFormat.PCL);
    doc.Close();

    // Read the generated file from the VFS and trigger the download
    const fileArray = window.dotnetRuntime.Module.FS.readFile(outputFileName);
    const blob = new Blob([fileArray], { type: 'application/octet-stream' });
    const url = URL.createObjectURL(blob);
    const a = document.createElement('a');
    a.href = url;
    a.download = outputFileName;
    a.click();
    URL.revokeObjectURL(url);
  };

  return (
    <div style={{ textAlign: 'center', height: '300px' }}>
      <h1>Convert PDF to PCL</h1>
      <button onClick={convertPdfToPcl}>
        Start Converting
      </button>
    </div>
  );
}

export default App;

The generated PCL file, whose header states the PCL-XL language:

The generated PCL file, whose header states the PCL-XL language

FAQ

The output file name ends with .pcl, so why is the file still a PDF

Reason: The single-argument overload SaveToFile(fileName) always writes in PDF format — the extension takes no part in deciding the format, so a file whose name ends with .pcl still comes out as a document whose content is PDF.

Solution: Pass the output format explicitly as the second argument:

// Single argument: writes PDF
doc.SaveToFile(outputFileName);

// FileFormat.PCL: writes a real PCL file
doc.SaveToFile(outputFileName, pdfModule.FileFormat.PCL);

What to do about `Cannot found font(Arial) installed on the system.`

Reason: Converting to PCL means turning the text on the page into font subsetting instructions a printer can read, and the converter looks for fonts in /Library/Fonts/ in the virtual file system — an empty directory raises this error.

Solution: Send the font into the VFS before loading the PDF:

// Placed before LoadFromFile, the font is already in the VFS when the conversion runs
await window.spire.FetchFileToVFS('ARIAL UNICODE MS.TTF', '/Library/Fonts/', `${process.env.PUBLIC_URL}/font/`);

What format is the generated PCL file, and how do I open it

Reason: The output is PCL-XL (PCL6), and the file begins with ESC%-12345X@PJL ENTER LANGUAGE = PCLXL, followed by binary HP-PCL XL;2;0 data. It is not text, so opening it in an editor only shows garbage.

Solution: Hand it straight to a printer or print service that supports PCL; there is no need to open it by hand. To confirm the format is right, read the PJL declaration at the start of the file.
